SYSTEM PARAMETERS—WIRELESS SYSTEM FAULT CODES
47
WIRELESS SYSTEM FAULT CODES
Table 18 below lists the fault codes associated with the
control system. Included in this table are the available
fault codes, a description of each fault code, and the
suggested corrective action to clear the fault.
Table 18
DELAY TIMERS
Table 19 below lists the delay timers associated with the
control system. Included in this table are the available
timers and their descriptions.
Table 19
F.770
(Protocol 3)
Overflow from SSI encoder
Protocol 3 encoder
1. The current position of the door com-
pared to the fixed closed position has
exceed the maximal allowed range of
4095 increments
2. Set P.202 (used resolution of the
encoder) to a higher value and repeat
limit setting
3. Reset P.210—reset limits
NOTE: Fault F:760 may appear.
Fault Code
(Displayed Message)
Description Corrective Action
Fault Code
(Displayed Message)
Description Corrective Action
F.856 Wireless communication error between sta-
tionary and mobile unit.
1. Wrong address parametrized
2. Mobile unit broken
3. Battery empty
4. Heavy wireless noise
5. Stationary antenna broken or mounted
wrong
F.857 Battery low. Reversing edge battery needs to be
replaced. Replace with D size lithium ion
battery 3.8 volts (Part number 00111193),
Delay Timer Description
Acl1 = x Sec Auto close delay timer 1.
(Terminals 210 and 212)
Acl2 = x Sec Auto close delay timer 2.
(Terminals 230 and 233)
Acl3 = x Sec Auto close delay timer 3.
(Can be programmed to any
output)
