SPECIFICATIONS—MECHANICAL
54
SPECIFICATIONS
MECHANICAL
INPUTS
Enclosure
Dimension L x W x H (approx.)
Materials
Heat Sink
Black plastic w/semi-transparent cover window
16 ³/₄ x 8 ¹/₄ x 7 ³/₄ (425 x 210 x 195 mm)
• includes heat sink, brake resistor, and wall brackets
• excludes cable glands, optional switches, and circuit breakers
Polycarbonate Macrolon (no silicone)
Aluminum (natural)
Board Dimension Approx. 10.5 x 8 x 5.5 inches (270 x 200 x 140 mm)
Mounting Brackets Wall brackets integrated in bottom side of enclosure
Vertical installation only
Weight Approx. 11 lb. (5 kg.)
Protection Class/Rating TST FU3R-A: UL Type-4X Standard Enclosure
TST FU3R-AP: open type (Pollution Degree 2 environment only)
Operating Temperature Range:
Ambient
Storage
Enclosed type/open type (vertically mounted)
–4 to 122/149°F (–20 to 50/65°C) at 50% duty cycle of max. motor load
–4 to 113/140°F (–20 to 45/50°C) at 83% duty cycle of max. motor load
–4 to 104/131°F (–20 to 40/55°C) at 100% duty cycle of max. motor load
–13 to 158°F (–25 to 70°C)
Relative Humidity Up to 80% (non-condensing)
Vibration Low vibration installation, e.g. on a concrete wall
Conduit Entry Formed plastic conduit bosses
(appropriately sized holes for conduit must be drilled in boss locations)
Internal Power Consumption Max. 50 W
Fully assembled controller w/o running motor
Approval UL-listed power conversion equipment for US and Canada
Inverter control: UL 508C
24 V power supply output: Class 2
Marks/Stickers TST FU3-AP: UL/UR sticker and serial number
TST FU3P-A: UL sticker, serial number
“WARNING High Voltage” provided by Rytec.
Clock 24-hour real-time clock with integrated gregorian calendar
4-channel electronic timer
Accuracy limit: Max. 5 sec/day over full temperature range
Battery Socket prepared for lithium coin cell CR2032 (3 V)
Power Supply (Line Voltage) Standard 185–500 volt, single- or three-phase
External Fuse: 20 amp, class CC
