RYTEC System 4 User Manual

SYSTEM PARAMETERS—OPERATOR LEVEL PARAMETERS
30
SYSTEM PARAMETERS
The system parameters are grouped into two levels:
“OPERATOR LEVEL PARAMETERs” below and “SER-
VICE LEVEL 2 PARAMETERS” on page 31.
OPERATOR LEVEL PARAMETERS
Table 5 below lists the parameters available through the
Operator Level. Included in this table is a description of
each parameter and its available range and factory
default setting.
Table 5
Parameter Range Operator Level Parameters (Password Not Required)
Factory
Setting
P. 0 1 0 0–200 seconds Auto-close delay timer 1 — ACL1 (with activator connected to
input 5 — terminals 210 and 212)
0 = Off
Time door remains open after all activation and safeties are
clear
10
P. 0 1 1 0–200 seconds Auto-close delay timer 3 — ACL3 (0 = off)
The ACL3 timer is available for all doors. The input selected
will need to be programmed to operate through the ACL3
timer.
0
P. 0 1 5 0–200 seconds Auto-close delay timer 2 — ACL2 (with activator connected to
input 6— terminals 230 and 233)
0 = Off
Time door remains open after all activation and safeties are
clear
5
P.050
(Defrost
System Only)
0–3 Heater status
0: Off
1: On — low heat stage 1 heated blower or – heat lamps
2: On — medium heat stage 1 + 2 heated blower
3: On — high heat stage 1 + 2 + 3 heated blower
0
P.051
(Defrost
System Only)
0–1 Heater control (parameter P.050 must be set to on)
0: Manual
1: Automatic timer
0
P.055
(Defrost
System Only)
0–3 Blower control
0: Off
1: Low-speed
2: High-speed
3: Automatic (blower runs at high speed when door is open)
0
P.058
(Defrost
System Only)
5–600 minutes Heater timer on time 30
P.059
(Defrost
System Only)
5–600 minutes Heater timer off time 5
P. 9 9 9 Password (for accessing Service Level 2) is the number 10
Password (for accessing Service Level 1) is the number 5.
