RYTEC System 4 User Manual

SYSTEM PARAMETERS—SERVICE LEVEL 2 PARAMETERS
35
Table 8
Parameter Range Service Level 2 Parameters
Factory
Setting
P. 9 1 0 0–25 Display mode selection
The following variables are displayed:
0: Control sequence is displayed, i.e. door cycles, door open-
ing, timer, door closing.
1: [Hz] The current travel speed
2: [A] The current motor current
3: [V] The current motor voltage
4: [A] The current DC bus current
5: [V] The current DC bus voltage
6: [°C] The power stage temperature in °Celsius
7: [°F] The power stage temperature in °Fahrenheit
8: [s] The run time of the motor during the last door operation
9: [Increments] The current position
10: [Increments] The position of the reference
11: [Dig] Channel 1 value of the absolute encoder
12: [Dig] Channel 2 value of the absolute encoder
13: [V] Current reference voltage
14: Temperature inside the controller in celsius degrees
15: Temperature inside the controller in fahrenheit degrees
16: Transmission ratio from motor to encoder during opening
17: Transmission ratio from motor to encoder during closing
18: Rotation speed of the motor output shaft
19: Temperature of the encoder
20: Battery voltage of encoder
21: Number of position requisition without answer
22: Number of position requests from the board to the
encoder without an answer from the encoder
23: Wireless reversing edge signal strength during door travel.
Given in a percentage of signal. Percentage should remain
above 90% during travel
24: Numbers of wireless reversing edge errors during the last
door cycle
25: Time of the clock in the controller.
NOTE: Settings 14 and 15 are only available if optional
temperature sensor installed in the controller.
P. 9 2 0 Error history
(The controller stores the last eight errors in the error history.
The System 4 controller will time stamp the errors with the
date and time the error occurred.)
Error message 1 (most recent error)
Error message 2
Error message 3
Error message 4
Error message 5
Error message 6
Error message 7
Error message 8
Clear the complete error history
Exit the error memory, jump back to parameter
