SECTION VI ELECTRICAL SYSTEM
Interior light
Interior courtesy light
DIN 72601-K 12V 10W
Rear work lights for tractors with plat-
form
To replace the bulb, proceed as follows:
–
Remove the rubber gasket and then the glass cover.
–
Push down lightly on the bulb while turning it counter-clockwise as far
as it will go.
–
Pull out the bulb.
–
Push the new bulb fully into the holder, and, applying light downward
pressure, turn the bulb clockwise as far as it will go.
–
Refit the glass cover and the rubber gasket.Rear work lights for trac-
tors with platform.
Bulb: DIN 72601-H3 12V 55W
176
NOTE: Switch off the front and rear lights before cleaning them.
WARNING: CONNECT ONLY TO A 12 VOLT SUPPLY TO BOOST BAT
-
TERY.
