APPENDIX Combination of tractor and mounted implement
5) Calculation of the real rear axle load T
H tot
Record the calculated real and the permissible rear axle load given in the
instruction handbook for the tractor into the table.
6) Tyre load carrying capacity
Record double the value (two tyres) of the permissible load carrying
capacity into the table (see for instance documentation provided by the
tyre manufacturer).
Real value Permissible value Double permissible
TABLE according according to tyre load carrying
to calculation instruction handbook capacity (two tyres)
Minimum
Ballasting
Front/rear Kg --- ---
Total weight Kg Kg ---
Front axle load Kg Kg Kg
Rear axle load Kg Kg Kg
The minimum ballasting has to be attached to the tractor either in
form of a mounted implement or ballasting weight!
The calculated values must be less or equal ( ) the permissible
values!
D
