A solvent flow /
Trigger error
Closing of all valves
(CTM, Injection,
Gun)
Display of the
default on the
screen
Validation
by the user
Repeat the flushing cycle The solvent supply
valve is piloted, the
open gun input is at
1 but the flowme-
ter does not send
the information
The circuit is
blocked.
The solvent color
changer valve is
not open.
The flowmeter is
blocked.
The flowmeter
does not send
the signal. The
solvent pressure
is too low.
The fluid regula-
tor is not piloted
or defective.
Check the com-
plete circuit from
the supply to the
applicator. Check
that the output
on the card is
activated (LED
on).
Check the air
supply to the
valve.
Check that air is
coming from the
electrovalve.
Check the correct
operating of the
flowmeter, espe-
cially that the
gears are turning
freely.
Check that the
sensor and the
sensor connector
are correctly
screwed.
Check the supply
pressure.
Check that the
regulator pilot
output is piloted.
Check the correct
operating of the
pneumatic cells.
Check that the
regulator is
piloted with air.
Check the correct
operating of the
regulator.
Default
wording
Automatic
action
Expected
validation
Action following
to validation
Trigger Causes Remedies
