Position of the connectors
OUT8 (green) OUT8 is driven to 24V
OUT9 (green) OUT9 is driven to 24V
OUT10 (green) OUT10 is driven to 24V
IN1 (green) IN1 is driven to 24V
IN2 (green) IN2 is driven to 24V
IN3 (green) IN3 is driven to 24V
IN4 (green) IN4 is driven to 24V
IN5 (green) IN5 is driven to 24V
IN6 (green) IN6 is driven to 24V
IN7 (green) IN7 is driven to 24V
IN8 (green) IN8 is driven to 24V
IN9 (green) IN9 is driven to 24V
IN10 (green) IN10 is driven to 24V
Connectors status Description
1 Input connectors
2 Output connectors
3 Output power connectors
4 Connector to CCB
LED status Description
4
2
1
3
