Sames PPH 607 - 4 Diagrams; General; Paint Circuit

Revised A 26 6301
4. Diagrams
4.1. General
Note: PFA = teflon tubing should not be replaced with nylon tubing.
4.2. Paint circuit
Circuit cleaning (typically color change)
25 Compensation air
24 Shaping air
23 Bearing air
22 Turbine brake
21 Turbine drive
26 Microphone IN
41 Dump valve 1
53 Dump valve pilot 1
63 Regulator pilot
11 Paint supply 1
51 Paint valve pilot 1
56 Injector wash pilot
32 Injector wash solvent or air
43 Microphone OUT
31 External bellcup wash solvent or air
58 External bellcup wash pilot air
41 Dump 1
53 Dump valve pilot
63 Regulator pilot
11 Paint supply 1
51 Paint valve pilot 1
DES02090
58
31
43
32
56
51
11
63
53
41
26
21
22
23
24
25
OD 2,7/4 NYLON
OD 2,7/4 NYLON
OD 2,7/4 NYLON
OD 2,7/4 NYLON
OD 2,7/4 PFA
OD 4/6 NYLON
OD 2,7/4 PFA
OD 2,7/4 NYLON
OD 6/8 PFA
OD 6/8 NYLON
OD 6/8 PFA
OD 6/8 NYLON
OD 8/10 NYLON
OD 8/10 NYLON
OD 4/6 NYLON
OD 4/6 NYLON
Magnetic turbine
DES01016
41
53
63
11
51
OD 3/16" NYLON
OD 5/16" PFA
OD 5/16" PFA
OD 3/16"NYLON
OD 3/16" NYLON
Magnetic turbine
D:6/8 Nylon
D:2,7/4 Nylon
D:2,7/4 Nylon
D: 6/8 PFA
D:2,7/4 Nylon
