Sames PPH 607 - Manifold O-Rings; Pipette Robot Side

Revised A 78 6301
8. PPH 607 SCAR metric spare parts list (continued)
8.4. Manifold o-rings / pipette robot side
Item USA P/N Sames P/N Description Qty
B X9NVFP118 X9NVFP118 Screw M4 x 10 nylon flat head 3
E 1305033 1305033 Pipette bracket 1
Couterbored holes USA P/N Sames P/N Description Qty
11, 21, 22, 24, 25, 41 82-0884-11 J3STKL094 O-ring 7.65 x 1.78 chemically inert 6
23, 26, 31, 32, 43,
51, 53, 56, 58, 63
82-0410-19 J3STKL005 O-ring 5.28 x1.78 chemically inert 10
Couterbored holes USA P/N Sames P/N Description Qty
11, 21, 22, 24, 25, 41 1403759 1403759 Pipette 8 mm 6
23, 26, 31, 32, 43,
51, 53, 56, 58, 63
1403758 1403758 Pipette 6 mm 10
DES01112
E: Pipette bracket
Pipette
Screw (item B)
housing
Screw (item B)
housing
