Sames PPH 607 - Shaping Air; Compensation Air

Revised A 29 6301
4. Diagrams (continued)
4.7. Shaping air
24: The shaping air supply controls the pattern size
diameter and is controlled through a remote
transducer.
4.8. Compensation air
25: Compensation air stops shaping air shroud con-
tamination and is controlled through a remote
regulator.
24 Shaping air
25 Compensation air
DES01021
24OD 3/8" NYLON
Magnetic turbine
D:8/10 Nylon
DES01022
25
OD 5/16" NYLON
Magnetic turbine
D:6/8 Nylon
