6. Assembly and disassembly (continued)
6.7. Manifold (continued)
6.7.1. Disassembly (continued)
• Step 1: Remove all o-rings
• Step 2: Remove the solvent injector (item 2) then remove the two o-rings (item 2a) from the
solvent injector
• Step 3: Remove the restrictor (item 6) and then remove the two o-rings (item 5) from the restrictor.
• Step 4: Remove shaping air alignment pin (item 9).
• Step 5: Remove the alignment pins (item 10).
• Step 6: Remove the high voltage contact and screw assembly (item 1).
• Step 7: Remove the nano-valves (item 12), (see § 6.3.1 page 53 for details).
• Step 8: Remove the regulator (item 3), (see § 6.5.1 page 60 for details).
• Step 9: Remove the three screws (item 16), holding the pipette bracket.
• Step 10: Remove the pipette bracket (item 15).
• Step 11: Remove pipettes (item 4 and 14).
6.7.2. Assembly
Note: Clean all components and inspect for damage, replace if necessary.
• Step 1: Install o-rings coated with a light film of dielectric grease.
• Step 2: Install the solvent injector (item 2) equipped with the two o-rings (item 2a)
• Step 3: Install the restrictor (item 6) equipped with the two o-rings (item 5).
• Step 4: Install the shaping air alignment pin (item 9).
• Step 5: Install the alignment pins (item 10).
• Step 6: Install the high voltage assembly. (item 1).
• Step 7: Install the nano-valves (item 12), (see § 6.3.2 page 53 for details).
• Step 8: Install the regulator (item 3), (see § 6.5.2 page 60 for details).
• Step 9: Install the pipettes (item 4 and 14) equipped with their o-rings.
• Step 10: Install the pipette bracket (item 15), fit and secure with the three nylon screws (item 16).
