3. Technical characteristics (continued)
3.2. Working characteristics
Weight US units Metric units
Atomizer without cables or hoses 7.716 lbs 3.5 kg
Body only 2.97 lbs 1.35 kg
Bellcup with deflector 0.09 lbs 0.04 kg
Turbine 0.925 lbs 0.420 kg
Nano-valve 0.013 lbs 0.006 kg
UHT 153 cascade 0.718 lbs 0.326 kg
Voltage
Maximum operating voltage 90 kV
Speed
Recommended rotation speed 15 to 45 KRpm 15 to 45 K tr/min.
Paint
Flow rate 0 to 500 cc/ min. Max (according to paint used)
Pressure normal setting 90 to 120 PSI 6 to 8 bar
Pressure maximum setting 150 PSI 10 bar
Viscosity range 20 to 40 seconds - FORD cup # 4
Air pressure
Nano-valve pilot 90 - 150 PSI 6 bar min. - 10 bar max
Bearing air 90 - 150 PSI 6 bar min. - 10 bar max
@ 85 l/min.
Shaping air 90 PSI constant 6 bar constant
Microphone air 25 - 45 PSI 1.9 to 3 bar constant
Air quality
Filtration (bearing air) must be dry, oil and dust free
Solids
< 5 mg /m
3
Oil < 2 mg / m3
Oil < 0.1 p.p.m
