Sames PPH 607 - Speed Settings

Revised A 47 6301
5. Maintenance (continued)
5.3.9. Speed settings
Note: These settings are typical examples. For more precise or different configurations, please
contact your SAMES Technologies representative.
65 EC bellcup for Metallic base coat
• Viscosity : 18 s Ford cup #4 @ 80° F
• Weight solids : 32 %
• Target distance : 9.5 inches
• Estat : 90 kV
60 mm negative edge bellcup for Base coat (solid)
• Viscosity : 34 s Ford cup #4 @ 80° F
• Weight solids : 44 %
• Target distance : 9.5 inches
• Estat : 90 kV
Settings Flow rates
(cc/min)
Shaping air
(l/min)
Bellcup speed
(kRpm)
Tip speed
(mm/s)
Pattern
Width (inch)
Film buid
(mils)
Low 100 100 29 75 23 0.43
Medium 135 130 35 75 21 0.52
High 160 155 42 75 21 0.65
Settings Flow rates
(cc/min)
Shaping air
(l/min)
Bellcup speed
(k Rpm)
Tip speed
(mm/s)
Pattern
Width (inch)
Film buid
(mils)
Low 150 120 29 75 27 0.75
Medium 190 150 36 75 24 0.9
High 230 180 43 75 26 1.1
