EB 5573-1 EN 141
Appendix
F Function WE System
Comments
Function block parameters: value range (default setting)
12 Creep feed rate
limitation
0
Not Anl
1.9
CO5 > F12 - 1: Creep feed rate limitation
Function block parameters:
Switching mode: Binary, analog (binary)
Active when BI = ON, OFF (ON)
14 Operation UP1 0
All
CO5 > F14 - 1: Feeder pump UP1 operation to cover own de-
mand
Note: the feeder pump UP1 also starts to operate to cover the
demand of RK2.
15 Release 0
All
CO5 > F15 - 1: Release controller at BI1
Function block parameters:
Active when BI = ON, OFF (ON)
16 Return ow
temperature
limitation
(proportional
controller)
0
All
CO5 > F16 - 1:
Return ow temperature limitation with P algo-
rithm
19 Monitoring 0
All
CO5 > F19 - 1: Temperature monitoring
20 Sensor calibra-
tion
1
All
CO5 > F20 - 1: Set all sensor calibration values
CO5 > F20 - 0: Delete all sensor calibration values
21 Lock manual
level
0
All
CO5 > F21 - 1: Lock rotary switch
In switch position, the controller runs in automatic mode
22 Lock rotary
switch
0
All
CO5 > F22 - 1: Lock rotary switch
Key number input is still possible.
23 0 to 10V
signal for
outdoor
temperature
0
All
CO5 > F23 - 1:
Outdoor temperature received or sent as 0 to
10V signal (terminals 11/12)
Function block parameters:
Direction: Input, Output (Input)
Lower transmission range: –30.0 to 100.0°C (–20.0°C)
Upper transmission range: –30.0 to 100.0°C (50.0°C)
F Function block number, WE Default setting, Anl System code number
