142 EB 5573-1 EN
Appendix
CO6 > Modbus (all systems)
F Function WE System
Comments
Function block parameters: value range (default setting)
01 Modbus 1
All
CO6 > F01 - 1: Modbus active
02 16-bit address 0
All
CO6 > F02 - 1: Modbus 16-bit addressing
(only with CO6 > F01 - 1)
CO6 > F02 - 0: Modbus 8-bit addressing
03 Modem 0
All
CO6 > F03 - 1: Modem function
(only with CO6 > F01 - 1 and CO6 > F08 - 1)
04 Automatic con-
guration
0
All
CO6 > F04 - 1: Automatic modem conguration
(only with CO6 > F03 - 1 and CO6 > F08 - 1)
05 Lock dial-up to
building auto-
mation system
0
All
CO6 > F05 - 1: Lock dial-up to building automation system
(only with CO6 > F03 - 1)
06 Dial-up also
upon corrected
error
0
All
CO6 > F06 - 1: Dial-up to building automation system also to
indicate that an error has been corrected (only when CO6 >
F03 - 1)
07 Monitoring 0
All
CO6 > F07 - 1: Control system monitoring > Resets all level bits
to “autonomous“ when there is no communication(only with
CO6 > F01 - 1)
08 Text message 0
All
CO6 > F08 - 1: Text message function active
10 Meter bus
(TROVIS5573-
100x only with
optional Mod-
bus/meter bus
gateway)
0
All
CO6 > F10 - 1: Meter bus active
Function block parameters:
WMZ1...x address*/0 to 255 (255)
WMZ1...x model code*/1434, CAL3, APAtO, SLS (1434)
WMZ1...x reading mode*/24h, CONT, CoiL (24 h)
* TROVIS5573-100x: WMZ1...6; TROVIS5573-110x: WMZ1...3
11 Flow rate
limitation in
RK1
0
Not Anl
1.9
CO6 > F11 - 1: Flow rate limitation (only with CO6>F10- 1
and when WMZ1 is activated)
Function block parameters:
Max. limit/At, 0.01 to 650m³/h (1.5m³/h)
Max. limit for heating*/At, 0.00 to 650m³/h (1.5m³/h)
Max. limit for DHW*/0.01 to 650m³/h (1.5m³/h)
Limiting factor/0.1 to 10 (1)
12 Capacity
limitation in
RK1
0
Not Anl
1.9
CO6 > F12 - 1: Capacity limitation (only with CO6>F10- 1
and when WMZ1 is activated)
Function block parameters:
Max. limit/At, 0.1 to 6500kW (1.5kW)
Max. limit for heating*/At, 0.0 to 6500kW (1.5kW)
Max. limit for DHW*/0.1 to 6500kW (1.5kW)
Limiting factor/0.1 to 10 (1)
