5 - 4 HS70A Service Manual
HS70A's major structure includes the following:
Ultrasound System Part
BF(Beamformer Board) 3ea 192ch
PSA(Probe Select Assembly) 4 Ports
BE(Back End Board)
AC(Analog Control Board)
USB ECG Module
USB Foot Switch
Gel Warmer
Easy Install System FAN
User Interface Part
23” Wide LED Monitor
10.1” Touch LED Backlight LCD
Key Matrix Board
Alpha Numeric Key Board
1.2” Track Ball
SW ECG
Easy Touch on the side of the touch
PC Part
PC Module : COM Express I,
CPU : Intel Core i7-3635QM(2.4G, 6M)
RAM : DDR3 SDRAM 8GB(4GB*2)
HDD : SSD 512G
VGA : Internal VGA(Intel HD4000)
Power Module
DDM
ACM
