5 - 2 HS70A Service Manual
Probes
The probe is a device that sends and receives ultrasound for acquiring image data. It is also
called a Transducer or Scanhead.
The system limits patient contact temperature to 43°C, and acoustic output values to their
respective U.S. FDA limits. A power protection fuse circuit protects against overcurrent
conditions. If the power monitor protection circuit senses an overcurrent condition, then the drive
current to the probe is shut off immediately, preventing overheating of the probe surfaces and
limiting acoustic output.
▌ Probe List
The ultrasound image scanner uses probes to obtain graphic data of the human body and
then displays it on the screen. Always use application-specific probes in order to obtain the
best quality images. It is also important to use a preset that is best suited to the particular
organ being scanned.
■ Probe Application and Presets
The types of probes, applications, and presets available with this product are as follows:
Probe Application Preset
L3-12A
Small Parts Bowel, Breast, Breast1, Testicle, Thyroid
Vascular Arterial, Carotid, Venous
MSK Shoulder/Knee, Hand/Foot, Elbow/Wrist, Penetration, Pediatric Hip
OB 1
st
Trimester
Abdomen General, Superficial, Pediatric ABD
LA3-16A
Small Parts Bowel, Breast, Testicle, Thyroid
Vascular Arterial, Carotid, Venous
MSK Shoulder/Knee, Hand/Foot, Elbow/Wrist, Penetration
LA3-16AI
MSK General, Superficial
Intraoperative General
LA2-9A
Small Parts Bowel, Breast, Testicle, Thyroid
Vascular Arterial, Carotid, Venous
Abdomen General
MSK General
LA4-18B
Small Parts Breast, Testicle, Thyroid
Vascular Carotid, Superficial
MSK General, Superficial
CA1-7A
Abdomen Aorta, General, General1, Pediatric ABD, Penetration, Renal, Urology
OB 1
st
Trimester, 2
nd
Trimester, 3
rd
Trimester, Fetal Heart, NT
To Next Page
