2 - 2 HS70A Service Manual
Specifications
Physical
Dimensions
Height: 1,430 – 1,710mm (with monitor)
Width: 557mm
Depth: 791 – 860mm
Weight: 99.4kg (with monitor)
Weight: Approx. 124kg (with Safe Working Load)
Imaging Modes
2D Mode
M Mode
Color Doppler
Pulsed Wave (PW) Spectral Doppler
Continuous Wave (CW) Spectral Doppler
Tissue Doppler Imaging (TDI)
Tissue Doppler Wave (TDW)
Power Doppler (PD)
Directional Power Doppler (S-Flow)
Color M Mode
Anatomical M Mode
3D imaging Mode
4D imaging Mode
ElastoScan Mode
Gray Scale
256 (8 bits)
Focusing
Transmit focusing, maximum of eight points (four points simultaneously selectable)
Digital dynamic receive focusing (continuous)
Probes
(Type BF/IPX7)
Linear Array
L3-12A, LA3-16A, LA3-16AI, LA2-9A, LA4-18B
Convex
CA1-7A, CA2-8A, CF4-9, CA3-10A, CA2-9A
Endocavity
E3-12A, VR5-9, EA2-11B
Phased Array
PA3-8B, PE2-4, PA4-12B, PA1-5A
3D
CV1-8A, LV3-14A, V5-9
CW
CW4.0, CW6.0, DP2B, DP8B
TEE
MMPT3-7
Probe
Connections
Four Active Probe Ports (include one CW probe port)
Five Active Probe Ports for option (include one CW probe port)
