Chapter 2. Introduction 2 - 3
Monitor
Main Monitor
23 inch Full HD LCD monitor (LED Backlight unit, hereafter referred to as “LCD
monitor”)
Touch Screen Monitor
10.1 inch LCD monitor (LED Backlight unit, hereafter referred to as “LCD monitor”)
ECG
USB Type (Type CF)
Rear Panel
Input/Output
Connections
Audio out
Microphone in
External Trigger out
External monitor DVI-I
Network
USB
S-VHS Video out
Composite Video out
Image Storage
Maximum 12,700 frames for Cine memory
Maximum 8,192 lines for Loop memory
Image filing system
Application
Obstetrics, Gynecology, Urology, Abdomen, Vascular, Small Part, MSK, Pediatric,
Cardiac, TCD, Intraoperative
Electrical
Parameters
100-240V~, 1100VA, 50/60Hz
Measurement
Packages
OB, Gynecology, Cardiac, Vascular, Fetal Heart, Urology, Abdomen, Small Parts,
MSK, TCD, Pediatric Hips
* Refer to ‘Chapter 9. Measurements and Calculations’ for additional information
Signal
Processing
(Pre-Processing)
TGC Control (Digital/Slider)
Mode-independent gain control
Acoustic power control (adjustable)
Dynamic aperture
Dynamic apodization
Dynamic range control (adjustable)
Image view area control
M-mode sweep speed control
Signal
Processing
(Post-
Processing)
Frame average
Edge enhancement/blurring
Gamma-scale windowing
Image orientation (left/right, up/down, and rotation)
White on black/black on white
Zoom
