Samsung HS70A - Monitor Arm Disassembly

Chapter 8. Disassembly and Assembly 8 - 9
Monitor Arm Disassembly
1. Push the edge of the Coverdml and pull in the arrow direction to detach (not screw).
2. Remove 2 screws and detach the left cap.
3. Cut the cable ties and detach 2 connectors.
