▐ Operational Principles of DSP Part
Image Data Processing in BW Mode and M Mode
RF Data generated by the BF Board is entered as FPGA Input.
The entered RF Data is converted into computable RF Data at FPGA Input, and then
entered as the input for ASIC (MCB028A).
ASIC(MCB028A) generates BW mode Image Data (hereinafter, BW Data) and sends it to
FPGA.
ASIC(MCB028A) creates BW Data and processes FSI (Full Spectrum Image), Spatial
Compound Imaging (SCI), Trapezoidal imaging, Synthetic aperture, and more.
To generate BW Data, it receives RF Data input and go through the process of DTGC
(Digital Time Gain Compensation), Decimation, Quadrature mixer, Envelope detection, Log
compression and several filtering.
BW Data generated by ASIC (MCB028A) as described above is entered into FPGA again. It
goes through FSI (Full Spectrum Image) and Lateral filter to remove Multibeam artifact and
BW Data is sent to FPGA.
Note that the BW Data can be used as Motion mode Image Data.
Doppler Image Data Processing
RF Data generated by the BF Board is entered as FPGA Input.
The entered RF Data is converted into computable RF Data at FPGA, and then entered
as the input for ASIC (MCB028A).
ASIC (MCB028A) receives RF Data input and processes through DTGC (Digital Time
Gain Compensation), Decimation, Quadrature Mixer, etc. to create I/Q data (In-phase &
Quadrature Data). I/Q Data is entered into FPGA again.
I/Q Data is processed at FPGA to generate Doppler Data and it is sent to DMA & RTC
Part. Detailed descriptions are as follows.
FPGA which received I/Q Data filters the data and filters CW I/Q Data from CW Board
in the same way to send the final Doppler Data to PC Part. PW and CW cannot be
processed simultaneously, therefore all operations are controlled by the internal control
process.
In addition, I/Q Data go through a Clutter Filter and are sent to a FFT (Fast Fourier
Transform) circuit for generating Doppler Spectrum, which isolates the basic elements
of Doppler, i.e. power, velocity, and variance, to generate Doppler Data. It is entered
into DSP FPGA again and is sent to DMA & RTC Part of BE Board.
Doppler Sound Filtered I/Q Data from FPGA go through the Clutter filtering to remove
the Wall Noise from Doppler DSP and is processed with Hilbert transform. The direction
of sound is removed to generate Doppler Sound.
