5 - 36 HS70A Service Manual
– TEE Temperature = 43.0°C: Estimated surface temperature of 43.0°C. Please reduce the
power value. Surface Temperature Reached: Currently 43.0°C.
– 43.0°C < TEE Temperature ≤ 50.0°C: Critical scanhead temperature. The system has
stopped transmit and returned to the Probe Selection Dialog.
– 50.0°C < TEE Temperature or TEE Temperature < 5.0°C: Error condition detected. The
System has stopped transmit and returned to the Probe Selection Dialog. Please contact
a Service Representative.
For the MPTEE probe, the following warnings are displayed, depending on the status of the
circuit:
– Short circuit or open circuit: Error condition detected. The System has stopped transmit
and returned to the Probe Selection Dialog. Please contact a Service Representative.
The probe is intended to be inserted into the human body; always keep it clean.
Never place the probe on the floor.
NOTE
■ When the probe is not in use, place it in the probe holder located on the left
side of the console. The probe holder on the right side is not suitable for the
MPTEE probe.
■ We recommend that you use pyrogen-free sheaths.
▌ Maintenance
Proper cleaning and disinfection prevent infectious diseases. The user must clean and
disinfect the probe by using an effective method, such as the one described in this user
manual.
Do not allow the handle or the probe connector to come in contact with
cleansing agent or disinfectant. Clean the handle and the cable with a moist
cloth; disinfect only the area between, and including, the scan head at the end
of the probe and the area marked as 100cm.
■ Cleaning
Never clean the probe with methanol or ethanol. Doing so may cause serious
problems with the product.
1. Remove the parts that do not need to be cleaned, and then clean the scan head and the
cable with gauze soaked in non-irritant cleansing solution. Mix non-irritant cleaning agent
in lukewarm water to prepare the cleansing solution; the recommended water
temperature is 26°C or lower.
