3 - 22 HS70A Service Manual
▐ Information
 Direction Marker
Set the Direction Marker. Select between SAMSUNG HS70A and HS70A.
 Doppler Axis
Select the units of measurement for the axis scale in Spectral Doppler Mode.
- cm/s: Specify the Doppler axis scale unit as cm/s.
- m/s: Specify the Doppler axis scale unit as m/s.
- kHz: Specify the Doppler axis scale unit as kHz.
▐ Wide Screen Mode
The Wide Screen mode can be turned on or off by using the trackball in Single, Dual, or
Quad mode. Turn this option off to set the screen to 4:3 ratio.
▐ Display
 TGC Line: Select whether or not to display the TGC Line. If this feature is not used,
TGC line is displayed on the screen for 3 seconds when TGC is configured.
 Image Info: Show or hide the image information. If the image information intrudes
too much on the screen, disable this option to hide it.
 TI(Thermal Index) Display: Specify the TI to display on the screen as TIs (Soft tissue
Thermal Index), TIb (Bone Thermal Index), or TIc (Cranial bone Thermal Index).
 Patient Name with
- Age: Select whether to display the name and age under the patient ID.
- Birthday: Select whether to display the name and date of birth underneath the patient
ID.
NOTE
'Age' and 'Birthday' cannot be used simultaneously.
 OB Display
Specify how the LMP, GA and EDD entered in the Patient Information screen will be
displayed on the monitor screen. Select two from LMP, GA, and EDD.
- Replace Patient ID (on Top info bar): Replace the ID in the title area.
