A21F F32 User Volt 1 25 0 100 % X W O
A220 F33 User Freq 2 25.00 0 400.00 Hz X W O
A221 F34 User Volt 2 50 0 100 % X W O
A222 F35 User Freq 3 37.50 0 400.00 Hz X W O
A223 F36 User Volt 3 75 0 100 % X W O
A224 F37 User Freq 4 50.00 0 400.00 Hz X W O
A225 F38 User Volt 4 100 0 100 % X W O
A226 F39 Volt Perc 100.0 40.0 110.0 % X W O
A227 F40 Energy save 0 0 30 % O W O
A231 F50 ETH select 1 0 1 O W O
A232 F51 ETH 1min 150 contPerc[0] 200 % O W O
A233 F52 ETH cont 100 50 ethPerc[0] % O W O
A234 F53 Motor type 0 0 1 O
W O
A235
F54
OL level
150
30
150
%
O
W
O
A236
F55
OL time
10.0
0
30.0
sec
O
W
O
A237
F56
OLT select
1
0
1
O
W
O
A238
F57
OLT level
180
30
200
%
O
W
O
A239
F58
OLT time
60.0
0
60.0
sec
O
W
O
A23A
F59
Stall prev.
0
0
7
X
W
O
A23B
F60
Stall level
150
30
200
%
X
W
O
A23C
F61
OutVolt Supp
0
0
1
X
W
O
A23D
F62
Input AC Vol
310
310
480
V
O
W
O
A23E
F63
UP/DN SAVE
0
0
1
X
W
O
A23F
F64
UP/DN FREQ
0
0
400.00
Hz
O
W
O
A240
F65
UP/DN Mode
0
0
2
X
W
O
A241 F66 UP/DN Step 0 0 400.00 Hz X W O
A245 F70 Draw Mode 0 0 3 X W O
A246 F71 Draw Percent 0 0 100.0 % O W O
FU2 GROUP
A300 H1 Last Fault1 0 0 1 O R O
A301 H2 Last Fault2 0 0 1 O R O
A302 H3 Last Fault3 0 0 1 O R O
A303
H4
Last Fault4
0
0
1
O
R
O
A304 H5 Last Fault5 0 0 1 O R O
A305 H6 Fault Clear 0 0 1 O W O
A306
H7
Dwell freq
5.00
0
400.00
Hz
X
W
O
A307
H8
Dwell time
0.0
0
10.0
sec
X
W
O
A309 H10 Jump freq 0 0 1 X W O
A30A H11 jump lo 1 10.00 0 jumpHiFreq[0] Hz X W O
A30B H12 jump Hi 1 15.00 jumpLoFreq[0] 400.00 Hz X W O
A30C
H13
jump lo 2
20.00
0
jumpHiFreq[1]
Hz
X
W
O
A30D H14 jump Hi 2 25.00 jumpLoFreq[1] 400.00 Hz X W O
A30E H15 jump lo 3 30.00 0 jumpHiFreq[2] Hz X W O
A30F H16 jump Hi 3 35.00 jumpLoFreq[2] 400.00 Hz X W O
A310
H17
Curve Time
40
1
100
%
X
W
O
A311 H18 Curve Time1 40 1 100 % X W O
A312 H19 Trip select 0 0 3 O W O
A313
H20
Power-on run
0
0
1
O
W
