A314 H21 RST restart
0 0 1 O W O
A315 H22
Speed Search
0 0 15 X W O
A316 H23 SS Sup-
Curr
100 80 200 % O W O
A317 H24 SS P-
gain
100 0 9999 O W O
A318 H25 SS I-gain
200 0 9999 O W O
A319 H26
Retry number
0 0 10 O W O
A31A H27 Retry delay
1.0 0 60.0 sec O W O
A31D H30 Motor select
0 0 maxMotNum
X
W
O
A31E H31
Pole number
4 2 12 X W O
A31F H32 Rated-Slip
2.00 0 10.00 Hz X W O
A320 H33 Rated-Curr
1.8 5 150.0 A X W O
A321 H34 Noload-Curr
7 1 100.0 A X W O
A322 H35 Motor Input
0 0 2 X W O
A323 H36 Efficiency 72 50 100 % X W O
A324 H37 Inertia rate 0 0 2 X W O
A325 H39 Carrier freq 3.0 1.0 15.0 KHz O W O
A327 H40
Control Mode
0 0 3
X
W
O
A328 H41 Auto Tune
0 0 1 X W O
A329 H42 Rs
2.500 0 28.000
Ω
X W O
A32B H44 Lsigma
26.00 0 300.00 mH X W O
A32C H45 SL P-Gain
1000 0 32767 O W O
A32D H46 SL I-Gain
100 0 32767 O W O
A32E H47 TRQ Limit
180.0 100.0 220.0 % X W O
A32F H48
PWM Mode
0 0 1 X W O
A330 H49 Set PID
0 0 1 X W O
A331 H50
PID F/B
0 0 2 X W O
A332 H51 PID P-gain
300.0 0 999.9 % O W O
A333 H52 PID I-time
1.00 0.10 32.00 sec O W O
A334 H53 PID D-time
0 0 30.00 sec O W O
A335 H54
Process PID
0 0 1 X W O
A336 H55 PID limitH
50.00 pidLimitFreqL 400.00 Hz O W O
A337 H56 PID limitL 0.50 0 pidLimitFreqH Hz O W O
A338 H57 PID Ref. Set
0 0 4 X W O
A33A H59 PID Out Inv.
0 0 1 X W O
A33B H60 Self-Diag
0 0 maxSelfDiag X W O
A33C H61
Sleep Delay
60.0 0 2000.0 sec X W O
A33D H62 Sleep Freq.
0 0 400.00 Hz O W O
A33E H63
WakeUp Level
2.0 0 50.0 % O W O
A33F H64 KEB Select
0 0 1 X W O
A340 H65
KEB StartLev
125.0 110.0 140.0 % X W O
A341 H66
KEB StopLev
130.0 kebStartLevel 145.0 % X W O
A342 H67
KEB Gain
1000 1 20000 X W O
A344 H69
Acc/Dec ch F
0 0 400.00 Hz X W O
A345 H70 Acc/Dec freq
0 0 1 Hz
X
W
O
A346 H71
Xcel T Mode
1 0 2
O
W
O
A347 H72
PowerOn disp
0 0 17 O W O
A348 H73 User disp
0 0 2 O W O
A349 H74 RPM fact
or
100 1 1000 % O W O
