-135-
Mechanical Parts List
KR7-XP200L00
Polarized-In Assembly
S04
TYPE-L
L03L-G/L03R-G
L04-B
(Green)
(Red)
(Blue)
L03L-B/L03R-B
L04-G
L04-R
L03L-R/L03R-R
M09
M09
M09
Note:
Parts for L03 differs according to type of LCD
panel/prism assembly.
M12
Refer to the chapter of optical disassembly
for the mounting direction of each part.
