Sartorius Combics 3 Series User Manual

101
Sample Printouts
For details on the individual
information blocks, see “Configuring
Printouts.” For details on configuring
the header lines, refer to the chapter of
the respective application.
“Weighing” application
The “Application initialization data"
information block is empty. If selected,
an empty line will be printed.
Display with ID and weighing platform:
HEADER LINE1
HEADER LINE2
14.01.2010 09:43
--------------------
Ser.no. 80705337
G# + 1.402 kg
T + 0.200 kg
N + 1.202 kg
--------------------
“Counting” application
The initialization data block contains
the reference sample quantity and the
reference sample weight.
The results block contains gross, net
and tare weight and the piece count as
a result.
HEADER LINE1
HEADER LINE2
14.07.2010 09:43
--------------------
nRef 10 pcs
wRef + 0.035 kg
G# + 1.402 kg
T + 0.212 kg
N + 1.190 kg
Qnt 34 pcs
--------------------
Data Interfaces
“Neutral Measurement” application
The initialization data block contains
the reference sample quantity and
reference weight. The results block
contains gross, net and tare weight
and the piece count as a result.
HEADER LINE1
HEADER LINE2
Ref 2 o
wRef + 1.200 kg
G# + 14.700 kg
T + 0.300 kg
N + 14.400 kg
Qnt 12 o
--------------------
“Weighing in Percent” application
The initialization data block contains
the reference percentage and reference
weight. The results block contains
gross, net and tare weights, as well
as the percentage, which is shown as
either the loss or the residual amount.
Percentage = residual
HEADER LINE1
HEADER LINE2
14.07.2010 09:43
--------------------
pRef 100 %
Wxx% + 2.100 kg
G# + 1.859 kg
T + 0.200 kg
N + 1.659 kg
Prc 79 %
--------------------
Percentage = loss:
:
:
D 21 %
--------------------
“Checkweighing” application
The initialization data block contains
the target weight, the minimum and
maximum load. The results block
always contains the gross, net and
tare weight. Additional results can be
printed in 2 different display types:
– Weight display:
In the OK and nonconforming range,
the deviation from the target weight
is always printed as a percentage and
absolute deviation.
– Relation to target value:
In the OK range, the deviation from the
target weight is printed as a percentage
and absolute deviation. In the
nonconforming range, “HH" is printed
for exceeding the weight and “LL" for
falling below the weight.
OK range in the weight and tolerance
limit display
HEADER LINE1
HEADER LINE2
14.07.2010 09:43
--------------------
Setp + 1.300 kg
Min + 1.235 kg
Max + 1.365 kg
G# + 1.312 kg
T + 0.000 kg
N + 1.312 kg
Lim + 0.92 %
W.Diff+ 0.012 kg
--------------------
Nonconforming range in the weight
display
:
:
Lim - 7.69 %
W.Diff- 0.100 kg
--------------------
Result outside (under) “OK” range;
“Threshold” printout:
:
:
Stat LL
--------------------
Result outside (over) “OK” range;
“Threshold” printout:
:
:
Stat HH
--------------------
