Sartorius Combics 3 Series User Manual

89
Specifications
Serial interface: Interface operating mode: Full duplex
Level: COM1: RS-232,
COM2: RS-232,
UniCOM (optional): RS-232 or
RS-422/485 half duplex
Connection: IP44 devices:
25-pin D-Sub socket
IP69K devices:
Connection via screw terminals in the housing,
cable routed into the housing via a cable gland.
Transmission rate: 150, 300, 600, 1200, 2400, 4800, 9600, 19200 baud
(depending on the operating mode)
Number of data bits: 7, 8 bits
Parity: Space, odd, even, none (depending on the
operating mode)
Number of stop bits: 1 or 2
Handshake mode: Software (XON/XOFF), hardware (1 character after CTS)
Protocols: SBI, XBPI-232
2)
, XBPI-485
1)2)
, SMA,
Profibus (UniCOM only)
various printers:
– YDP01IS – YDP02IS label
– YDP01IS label – Universal
– YDP02 – YDP04IS
– YDP03 – YDP04IS label
– YDP02IS – YAM01IS Alibi memory
Network address
3)
: 0, 1, 2, ..., 31
SBI: Manual data output: Without stability, after stability, configurable printout
SBI: Auto. data output: Without stability, at stability, at user-defined intervals
SBI: Output format: 16 or 22 characters
Printout of application data: Output of a configurable printout
Factory Settings Depends on the device configured; for example: “SBI," “Data communication" setting
Transmission rate: 1200 baud
Number of data bits: 7 bits
Parity: Odd
Number of stop bits: 1 stop bit
Handshake: Hardware handshake, 1 character after CTS
Activation of data output: Individual print out after stability
Time-dependent autoprint: 1 display update
Output format: 22 characters
Analog UniCOM interface (optional) Level: 4…20 mA, 0…20 mA, 0…5 V
Power supply: Internal or external
Factory setting: 4...20 mA, internal power supply
Connection: CAISL3 devices (IP44):
25-pin D-Sub socket
CAIS3 devices (IP69K):
Connection via screw terminals in the housing,
cable routed into the housing via a cable gland.
1)
Optional UniCOM universal data interface
2)
xBPI operating mode: 9600 baud, 8 data bits, parity: odd, 1 stop bit
3)
Network address is valid only in xBPI-RS-485 operating mode
Data Interfaces
