Data Interfaces
The indicator is equipped with the following data interfaces:
– COM1: Standard data interface (RS-232)
– COM2: Standard data interface (RS-232)
– UniCOM: Universal data interface (optional)
Interfaces can be configured in the Setup menu for different input and output functions
(e.g. printer, 3rd weighing platform, PC, checkweighing).
The optional UniCOM interface can be used as an RS-232, RS-485/RS-422 or analog output
(voltage/current interface, galvanically separated digital I/Os, profibus, Ethernet), see also
“Accessories."
A barcode scanner or a keyboard can be connected via the PS/2 -socket or the corresponding
screw terminals (IP69K).
Features
– IP44 indicator:
Connect via a 25-pin D-Sub female connector
– IP69K indicator:
Route the connecting cable from the peripheral device to the indicator via a cable gland.
The free cable ends are connected via the screw terminals.
3
Warning when using third-party RS-232 connecting cables:
The pin assignments may not be compatible with Sartorius equipment.
Check the pin assignment against the cabling diagrams and disconnect any lines that are
not assigned. Failure to do so may cause malfunction, damage or even completely ruin your
indicator and/or peripheral device(s).
88
