Operating Design
Special Character Input via the Keypad
t Press the a key.
y “ABC" is displayed.
t Press the 1 key.
y The corresponding character selection is displayed. The flashing cursor marks the first
character.
t Press the F1 soft key (l) or wait 2 seconds.
y The special character appears on the display.
Deleting characters
t Press c.
Deleting entire input string
t Press the F4 soft key (ESC).
Saving Input
t Enter a value.
t Press the corresponding soft key (e.g. 1.ID to define an identifier).
Saving Settings in Weighing Mode
You can specify the save type used in the Application Parameters
Setup menu.
By default, all application parameters saved (e. g., reference values) remain in memory
and are available when
– the device has been switched off and then on again
– you return to the originally selected application from a second one (e. g., when you
switch from Averaging back to Counting all parameters saved for Counting are available).
Applying the Tare Weight
To save the weight on the weighing platform as a tare weight:
t Place the tare object on the weighing platform.
t Press ).
y The value is applied as the tare value.
Input Through the Digital Control Port
You can connect a remote hand switch or foot switch to the input control line, for use
with all application programs. The following functions can be assigned in the Setup
menu
Device Parameters:Control I/O Ports:Universal
Switch Key:
–
Off – Zeroing key
– Print key – On key
– Print key 2 sec – CF key
– Tare key – F1 function key
– ISO test key – Appl. toggle key
– Fn key function – 10x higher resolution key
– WP toggle key – Net/gross value key
– Combined zero/
tare function
48
