Example
The command character for output is “P" (“output to Port"). To trigger this command,
send the string: “ESC P CR LF”.
Command Meaning
K Weighing mode 1
L Weighing mode 2
M Weighing mode 3
N Weighing mode 4
O Block keys
P Send display value to data interface
Q Output acoustic signal
R Unblock keys
D Tare and zero
(combination tare function)
f3_ Zero (see also the “kZE_” command)
f4_ Tare without zeroing (see also the “kT_” command)
i_ Information about the indicator, example of output: “CAI/016302/1"
Meaning: Indicator: Combics 3, software version: 016302,
Active weighing platform: 1
kF1_ Trigger soft key F1 function
kF2_ Trigger soft key F2 function
kF3_ Trigger soft key F3 function
kF4_ Trigger soft key F4 function
kF5_ Trigger soft key F5 function
kF6_ Trigger R key function
kF7_ Trigger H key function
kF8_ Trigger D key function
kF9_ Trigger k key function
kF10_ Trigger J key function
kF11_ Trigger K key function
kF12_ Trigger L key function
kP_ Trigger p key function (print at printer interface)
kT_ Trigger T key (tare)
kNW_ Trigger n key function (toggle the weighing platform)
kZE_ Trigger ( key function (zero the instrument)
kCF_ Trigger c key function
x1_ Output model designation of active weighing platform, example:
“LP6200S-0C"
x2_ Output serial number of active weighing platform, example: “0012345678"
x3_ Output software version of active weighing platform, example: “00-43-04"
x4_ Output software version of indicator, example: “01-63-02"
x9_ Output serial number of indicator, example: “0012345678"
x10_ Output model of indicator, example: “CAIS3"
z1_ Input: printout header 1
z2_ Input: printout header 2
The ASCII code for the “underline” character (“_”) is 95.
Format for entering printout header lines: “ESC z x a ... a _ CR LF" with x=1 or 2 and
a ... a: 1 to 20 characters for header x, followed by the underline, CR and LF characters.
txx…x_ Write text in display. xx…x is the text to be displayed.
