PR 5211 Instrument Manual Commissioning
Sartorius EN-43
Number of load cells
Number of load cells connected in parallel (1, 2 .... 10)
Capacity of one load cell
Maximum capacity (E
MAX
) of one load cell (not the total load,
not the weighing range)
[Gravity]
Gravity at place of installation, as default value 9.81379 m/s²,
the value for Hamburg/Germany has been taken.
Sensitivity, Resistance
Data can be taken from the 'Calibration certificate' for the
specific load cell(s). For [Sensitivity] the Rated output and for
[Resistance] the output impedance has to be taken.
Hysteresis correction
Only if [with] has been selected, the data for [Correction A/B]
have to be entered. The data can be obtained from the load
cell certificate.
Press the button after entering the data to load the load cell
data into the device.
Select [Calibration].
The sequence has to be performed as described in chapter 4.11, only in step 4 [by load cell data] has to be
chosen.
