6.3.3 ADU parameter
6.3.3.1 Parameter P21: SetFullScale
Write only
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 FSD MSB
Byte 1 ""
Byte 2 FSD LSB
Byte 3 EXPONENT UNIT
FSD 3 bytes for the full scale deflection
EXPONENT (4 bit) Number of digits behind the decimal comma/point
UNIT (4 bit) weight unit (as in register 4)
6.3.3.2 Parameter P22: Stepwidth
Write only
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0
Byte 1
Byte 2
Byte 3 Stepwidth
Step width: 1, 2, 5, 10, 20, 50
6.3.3.3 Parameter P23: SetDeadload with Weight
Write only
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0
Byte 1
Byte 2
Byte 3 1
At writing to this parameter, the actual weight will be stored as deadload.
