12 Appendix
12.1 Pin Assignment for Interface RS-485
PR 5110:
Pin assignment female
PR 1627/PR 1628 with interface card PR 1604:
Pin assignment male
GND = 8 GND = 3
RxB = 2 RxB = 8
RxA = 3 RxA = 9
TxB = 7 TxB = 4
TxA = 5 TxA = 5
12.2 EC Declaration of Conformity
The certificate can be found in the directory Certificates on the CD-ROM delivered with the instrument.
12.3 GSD File for ProfiBus DP
The GSD file can be found in the directory ProfiBus-Files on the CD-ROM delivered with the instrument.
12.4 Spare Parts
Order number Description Beschreibung
5312 264 48012 Connector 4-pin Stecker 4-polig
5312 321 28052 PC connecting cable USB-A/B 1.8 m PC-Anschlusskabel USB-A/B 1,8 m
5312 447 98005 Blind cap Blindkappe
