PR 5211 Instrument Manual Technical Data
Sartorius EN-87
10.5 Mechanical Data
10.5.1 Construction Type
Polyamide housing, black, flammability class V0 (UL 94).
Protection class according to DIN 40050: IP 20.
10.5.2 Dimensions
Housing Dimensions
Width 45 mm
Height 99 mm
Depth 116 mm
10.5.3 Connections
- Via plug-in screw terminals, cross-section max. 2.5 mm
2
- 9-pin D-Sub connector (female) for ProfiBus
- USB-B for PC
10.5.4 Weight
Net weight 0.3 kg
Shipping weight 0.45 kg
10.6 Equipment Supplied
- Operation manual in English and German on CD-ROM
- ConfigureIt! to configure/calibrate the transmitter via PC on CD-ROM
- Connection cable for PC; length 1.8 m
10.7 Options
- Operation manual on paper (English), order no. 9499 050 52100
- Operation manual on paper (German), order no. 9499 050 52108
