Sartorius PR 5211 Series User Manual

PR 5211 Instrument Manual ProfiBus Interface
Sartorius EN-63
6.2 ProfiBus Register
6.2.1 Register 0: IO-Status Bits for Reading
Dynamic status, only reading is allowed.
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
byte 0
Input 3
Input 2
Input 1
byte 1
Output 3
Output 2
Output 1
byte 2
Limit 3
Limit 2
Limit 1
byte 3
6.2.2 Register 1: Scale Status
Dynamic status, only reading is allowed.
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
byte 0
DIM
STND
INZSR
CZERO
BELOW0
OVL
>FSD
ADUERR
byte 1
E1
E3
E7
byte 2
PowerFail
ActionActiv
CmdError
byte 3
TareActiv
CalChanged
TestActiv
Byte 0 corresponds to byte 7 in the output area, for weight errors see table in chapter 0.
ADUERR Errror in analog conversion/ load cell circuitry (OR-function of bits E1,E3,E7)
>FSD gross value larger FSD (german SKE), scale range exceeded
OVL scale overloaded, gross > FSD + Overload,
Error 2
BELOW0 Gross weight negative (< 0-1/4 d)
CZERO Center of zero, weight within 1/4d range
INZSR Gross weight is within zeroset range
STND Scale is in stand still
DIM Gross weight has exceeded the scale range (0-1/4d > weight > FSD+overload), (OR-funktion
of bits BELOW0, OVL).
E7 Measuring signal is negative (inverse conversion), Error 7
E6 Sense voltage missing/too low, Error 6
E3 Measuring signal is > 36mV (no end of conversion), Error 3
E1 Arithmetic error (overflow), Error 1
CmdError Error during execution (cmdError), e.g. action 'taring' is not executed as there is no
standstill. In LastError (register 4) the error is specified. With ResetError register
89/89+128 or register 121 the bit is reset again.
ActionActiv Action will be executed, is still processed
PowerFail Power failure, will be set at each power-on. With bit ResetPWF register 85/85+128 or
register 117) 'Power failure reset' the bit PowerFail is reset.
TestActiv Analog test is aktive
CalChanged Calibration mode is active or calibration data have been changed.
FSD has to be read again to reset this bit.
TareActiv Transmitter has beeen tared
