PR 5211 Instrument Manual Technical Data
Sartorius EN-85
10.2 ProfiBus DP
Standard EN 50 179 volume 2, PROFIBUS
DIN 19245: PROFIBUS, Process Field Bus (part 1 and 3)
Baudrates 9.6, 19.2, 93.75, 187.5, 500 [kBps], 1.5, 3.0, 6.0, 12.0 [MBps], automatic detection
Buffer size 8 bytes
I/O data 8 bytes
UserPrm No
Sync YES
Freeze YES
Clear YES
Set-Slave-Add No
10.3 Power Supply
Power voltage 24 VDC +10% / -15%
Power consumption 8.2 W
10.4 Environmental Effects
10.4.1 Environmental Conditions
Temperature range
Reference temperature 23 °C
Ambient temperature operation -10... +55 °C
Switch-on temperature 0... +55 °C
Storage/ transport -40... +70 °C
Humidity <95 %, without condensation, (acc. to IEC 68-2)
Protection type IP 20
Vibration to IEC 68-2-6, test Fc
