Data
format
code
Case 1 (df1: specified
or df1: and df2: omitted)
Case 2 (df2: specified)
(Only when using FeliCa Lite)
ID Block
ID (upper bit 16 digits)
ID (lower bit 16 digits)
Copy the IDd of D_ID block (12 digits)
DFC (4 digits)
Copy the IDd of D_ID block (16 digits)
ID (upper bit 16 digits)
ID (lower bit 16 digits)
Copy the IDd of D_ID block (12 digits)
DFC (4 digits)
Copy the IDd of D_ID block (16 digits)
* If the data format code is not specified (df1: and df2: omitted), DFC is set to [0000].
* For FeliCa Lite-S, case 2 cannot be used according to the IC chip specification.
* The ID copy process of D_ID block to ID block upper bit 16 digits is a feature available only when using
FeliCa Lite. FeliCa Lite-S is registered during the manufacturing stage of IC chip.
* If the ID block random code is omitted, [000000000000] will be set.
Parameters related to locking user block and subtraction register (omissible)
lck: User block lock Set a fixed 15-digit binary.
The bitmap image corresponds to the 14 scratch pad blocks (00H ~
0DH) and 1 subtraction block (0EH), and the block sequence is 00H ~
0EH from the left.
0 1 ･･････････ D E
Scratch pad block (14 digits)
Subtraction block (1 digit)
If this parameter is specified, the block specified to 1 can be locked
(read-only). Specified the block not to be locked to 0.
Note that once you lock the blocks, the locked blocks become read-only
and you cannot unlock them.
Parameters related to system block lock (omissible)
lsy: System block
lock
Set a fixed 2-digit binary.
0 1
System blocks (block number: 82H, 83H, 84H, 86H,
87H) and MC blocks (MC[2] to MC[5]) lock
* For FeliCa Lite, the lock range of MC block is MC[2]
to MC[4].
MC blocks (MC[0] to MC[1], MC[6] to MC[12]) lock
* For FeliCa Lite, the lock range of MC block is MC[0]
to MC[1].
If this parameter is specified, the system block specified to 1 can be
locked. Specified the block not to be locked to 0.
