SATO CL4NX Programming Reference

501
Detailed parameters of NFC(NDEF) support (omissible)
Value Encryption type
04 60 GHz
ssi: SSID For ndf:5 ~ 6, specify the recognition name of the
access point to 1 ~ 32 digits.
Usable characters are 0 ~ 9, A ~ Z, a ~ z and the
following symbols:
! " # $ % & ' ( ) * + , - . / :
; < = > ? @ [ \ ] ^ _ ` { | } ~
* Space cannot be used.
The size information of the front data delimited by a
comma is necessary. For example if the data size is
32, specify as ssi:32,abcde....
nky: Network Key For ndf:5 ~ 6, specify the network key of the access
point to 8 ~ 63 digit.
Usable characters are 0 ~ 9, A ~ Z, a ~ z and the
following symbols:
! " # $ % & ' ( ) * + , - . / :
; < = > ? @ [ \ ] ^ _ ` { | } ~
* Space cannot be used.
The size information of the front data delimited by a
comma is necessary. For example if the data size is
8, specify as nky:8,AbCdEfGh.
atp: Authentication Type For ndf:5 ~ 6, specify the authentication type of the
access point to a fixed 4-digit hexadecimal.
Valid range: 0001 ~ FFFF (refer to the table of
"Setting value of Authentication Type (atp:)" in "[ESC
+RK] RFID write (ISO/IEC14443 TypeA)").
* Considering the extensibility of the function, only the digit
number is checked instead of its content.
etp: Encryption Type For ndf:5 ~ 6, specify the encryption type of the
access point to a fixed 4-digit hexadecimal.
Valid range: 0001 ~ FFFF (refer to the table of
"Setting value of Encryption Type (etp:)" in "[ESC
+RK] RFID write (ISO/IEC14443 TypeA)").
* Considering the extensibility of the function, only the digit
number is checked instead of its content.
• Detailed parameters related to NFC(NDEF) support is available if nfc: is set to 1. In addition, if nfc: is omitted, it will be
processed as 1 is set in NFC(NDEF) support parameters.
• Not available if nfc:is set to 0.
• Cannot be used together with wbs: and blt:.
• The data write will fail if the created data specified by the detailed parameters related to NFC(NDEF) support exceeds
the maximum byte of the targeted IC chip.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
