SATO CL4NX - Page 504

502
Detailed parameters of NFC(NDEF) support (omissible)
Maximum byte: 224 bytes (for both FeliCa Lite and FeliCa Lite-S)
Parameters related to feed control (omissible)
fsw: Feed without printing Normally, RFID write print jobs that don’t include print
data writes but don’t feed label. (Except for cases
with tag offset as default)
When 1 is specified for this parameter, even the print
jobs that don’t include print data will feed.
When 0 is specified, print jobs that don’t include print
data will not feed, which is the same as not specifying
fsw:. Also, printer only writes without feeding or
printing when 0 is specified for print jobs that include
print data, which allows write test without having to
waste label.
If don’t feed, Short buzzer will sound 2 times when
write is successful. Short buzzer will the sound 6
times when it fails to write.
In addition, if 2 is specified for the item including
print data, a write test can be performed without
consuming label as only write is executed without
feed/print.
Valid range: 0-2
[Coding sample 1] (data input format is set to ASCII)
Record 13 bytes character of [4912345678904] on the scratch pad
A format omitting RFID tag error ignore
<A>
<V>50<H>50<BD>3020654912345678904
<RK>4,D13,4912345678904
<Q>2
<Z>
[Coding sample 2] (data input format is set to ASCII)
Record 13 bytes character of [4912345678904] from block 5 on the scratch pad
(A format omitting b, RFID tag error ignore)
<A>
<V>50<H>50<BD>3020654912345678904
<RK>4,D13,4912345678904,wsb:5
<Q>1
<Z>
The scratch pad data after executing the example
Block
0
1
2
3
4
5
6
7
8
9.....13
Data
4912345678904XXX
Data in the block outside for writing is
maintained.
*
The remaining byte XXX will be filled with
NULL.
wsb: Specify write start block
[Coding sample 3] (data input format is set to ASCII)
