201
12. Rotate the liner rewinder (14) counterclockwise by hand, to wind the liner.
13. Close the print head.
14. Close the dispenser unit.
15. Press the media guide lightly against the end of the media, and then turn the knob
to lock the media guide.
16. Close the top cover.
• When closing the top cover, be careful not to pinch your fingers.
17. Perform a test print to make sure that the media is loaded correctly.
• You need to load the ribbon when printing using thermal transfer.
Removing the Liner from the Rewinder
• The rewinder can take up maximum a diameter of 120 mm (4.72") of liner.
1. Pull the clip (1) away from the printer and pull to remove the liner (2).
