SATO CL4NX - [Speed]

[Speed]
224
Disabled
Does not show the warning icon.
• The warning icon is shown in the status bar on the upper part of the screen.
[Speed]
The setting range varies depending on the print resolution of the printer.
The setting range of the print speed is as follows:
Resolution CL4NX CL6NX
203 dpi (8 dots/mm) 2 to 10 ips (inches/sec) (50.8 to 254
mm/sec)
2 to 10 ips (inches/sec) (50.8 to 254
mm/sec)
305 dpi (12 dots/mm) 2 to 8 ips (inches/sec) (50.8 to
203.2 mm/sec)
2 to 8 ips (inches/sec) (50.8 to
203.2 mm/sec)
609 dpi (24 dots/mm) 2 to 6 ips (inches/sec) (50.8 to 152
mm/sec)
-
• If the optional linerless cutter kit is installed to CL4NX, the setting range is as follows:
◦ The setting range is 2 to 6 ips (inches/sec) (50.8 to 152 mm/sec) regardless of the
printing resolution.
◦ If the [Speed] is set more than 7 ips (177.8 mm/sec), it is changed to 4 ips after
installing the linerless cutter kit.
• Setting the print speed to a level that is too fast may affect the print quality.
