Parts Identification
Parts Identification for the Printer
Front View
(1) Top cover
(2) NFC antenna location
*This feature is supported on printers from serial number 6B~ and above.
(3) Color LCD
(4) Operator panel
(5) Media discharge outlet
(6) USB connector (Type A)
Enable the storage of printer settings information with USB memory.
Also, other devices like a barcode checker, barcode scanner or keyboard can be connected.
• Be sure to perform a virus check on the USB memory before connecting it to the
printer. SATO Corporation shall not be held responsible for any printer malfunctions
caused by a virus spread via USB memory.
