Accessing to the Web Configuration Page
506
Configuring the Printer Settings from a Web Browser
Accessing to the Web Configuration Page
The printer can be operated through a web configuration page using any browser.
With an Ethernet LAN or WLAN connection, users can remotely get information from the printer or
perform the printer settings.
You need the printer IP address to access the web configuration page. The printer IP
address can be checked in [Settings] > [Information] > [IPv4 Address].
1. Open up the browser and enter the printer URL.
If the printer IP address is 192.168.143.123, enter the following URL: https://192.168.143.123
When a security certificate is prompted, you must acknowledge and click Continue.
The web configuration page appears. On the upper right (1) of each page, the model name, current
resolution and MAC address are shown.
2. Log in to view [Settings] and [Tools] pages.
You can view [Dashboard] and [Certificates] pages without logging in.
a. Click [Login] (2).
b. Select [settings] for the user, enter the password, and click [Login].
The default user is [settings], and the default password is "0310".

Table of Contents

Other manuals for SATO CL4NX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SATO CL4NX and is the answer not in the manual?

SATO CL4NX Specifications

General IconGeneral
Wi-FiNo
Ethernet LANYes
Flash memory2000 MB
Storage mediaFlash
Internal memory256 MB
Built-in barcodesCode 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity2 GB
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)30 - 90 %
Operating relative humidity (H-H)30 - 80 %
Maximum roll diameter220 mm
Maximum printing width104 mm
Printing media thickness0.06 - 0.26 µm
Display typeLCD
Product colorBlack
Display diagonal3.5 \
Display resolution320 x 240 pixels
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
USB connectorUSB Type-A / USB Type-B
Bluetooth version3.0
Serial interface typeRS-232C
USB 2.0 ports quantity2
Connectivity technologyWired & Wireless
TypePOS printer
Print speed10 ips
Print technologyDirect thermal / Thermal transfer
Maximum resolution203 x 203 DPI
Weight and Dimensions IconWeight and Dimensions
Depth457 mm
Width271 mm
Height321 mm
Weight15000 g
