SATO CL4NX User Manual

[Network]
260
•
After doing the settings, press the button to enable the new settings. Press
the button to cancel the new settings and return to the previous settings.
• You cannot change [IP Address], [Prefix Length], [Gateway], or [DNS] if [Mode] is
anything other than [Static].
[Mode]
Select the IP address assignment method or disable IPv6.
The options are as follows:
Disable
Disable IPv6.
Auto
Automatically generate the IP address and gateway (stateless mode).
DHCP
Automatically retrieve the IP address and gateway from the DHCP server (stateful mode).
Static
Manually set the IP address, gateway and prefix length.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
