SATO CL4NX User Manual

297
[Multiple connections]
Set whether to receive connection requests from multiple hosts or applications.
The options are as follows:
Enabled
While connecting with one host or application, the printer can receive connection requests from
other hosts or applications. The subsequent connection requests are put on hold, and processed
in order of reception after the first connection is closed.
Disabled
While connecting with one host or application, the printer cannot receive connection requests from
other hosts or applications.
• When you have selected [Enabled], be sure to use one port connection for Status3,
Status4, and Status5. Operation using two port connections for Status4 is not
guaranteed.
[Legacy Status for Port 9100]
Set whether to change the return status format of port3 to legacy status.
Does not appear if you have selected [None] in the [Flow Control] menu.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
