[External I/O]
366
Paper/Ribbon End (If RFID mode is enabled) (CL4NX only)
Set the output pin No. of the Signal Paper End.
Set the output pin No. of the Signal Paper/Ribbon End if you have installed the RFID.
Ribbon End
RFID Tag Error (If RFID mode is enabled) (CL4NX only)
Set the output pin No. of the Signal Ribbon End.
Set the output pin No. of the Signal RFID Tag Error if you have installed the RFID.
Machine Error
Machine/RFID Error (If RFID mode is enabled) (CL4NX only)
Set the output pin No. of the Signal Machine Error.
Set the output pin No. of the Signal Machine/RFID Error if you have installed the RFID.
Print Done
Set the output pin No. of the Signal Print End.
Qty
Offline
[Qty] is shown if [MODE1] is selected in the [EXT 9PIN] menu.
[Offline] is shown if [MODE2] is selected in the [EXT 9PIN] menu.
Set the output pin No. of the Signal Qty/Offline.
Ribbon Near End
Set the output pin No. of the Signal Ribbon Near End.
Dispenser
Set the output pin No. of the Signal Dispenser.
◦ Use this signal to connect the dispenser unit or linerless cutter kit (CL4NX only).
Label Near End
Set the output pin No. of the Signal Label Near End.
*This feature is supported on printers from serial number 6B~ and above.
The options for each signal output are as follows:
[PIN 1] Set the selected signal to pin 1.
[PIN 3] Set the selected signal to pin 3.
[PIN 4] Set the selected signal to pin 4.
[PIN 6] Set the selected signal to pin 6.
[PIN 9] Set the selected signal to pin 9.
[PIN 10] Set the selected signal to pin 10.
[OFF] Set the selected signal to off mode.
