SATO CL4NX User Manual

Status Icon
38
Icon Description
The Real Time mode of the SOS is enabled, but not connected to the SOS cloud.
If LAN or Wi-Fi icon is grayed out, the printer is not connected to the network.
If LAN or Wi-Fi icon is active, the Internet connection of the SOS cloud has a
trouble.
The time has come that set the periodic notification in the On-Demand mode of
SOS. Scan the QR code and send the information to the SOS cloud.
USB Memory Status
Icon Description
USB memory is connected.
Barcode Checker Status
Icon Description
Barcode checker is connected.
Barcode Scanner Status
Icon Description
Barcode scanner is connected in AEP mode.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
