SATO CL4NX User Manual

45
Show video fromNo. Guidance Videos
Error screen Startup Guide [Information]
Menu
11 Media roll replacement
(Linerless) (CL4NX only)
Possible - Possible
12 Media roll replacement
(Dispenser)
Possible - Possible
13 Media roll replacement
(Dispenser with rewinder)
Possible - Possible
14 Fan-fold media
replacement (Standard)
Possible - Possible
15 Fan-fold media
replacement (Cutter)
Possible - Possible
16 Ribbon replacement Possible - Possible
17 Print head replacement - - Possible
18 Platen roller replacement - - Possible
19 Cleaning - - Possible
Playing the Guidance Video from the Error Screen
Play the guidance video from the error screen and resolve the error by following the procedure of the
video.
1.
On the error screen, press the button to play the guidance video.
If there are more videos to choose from, press the arrow buttons to select the guidance video, and
then press the button. The guidance video starts.

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
